EMAT Thickness Gauge UT-3M-EMA is a new development featuring electromagnetic-acoustic (EMA) technology.

EMA method is used for measuring the material thickness based on the excitation of ultrasonic waves in the material by the generator of the device’s probe, and fixing the path time of ultrasonic waves in the material.

This new technology is similar to the common piezo-ultrasonic method, however, the EMAT Thickness Gauge NOVOTEST UT-3M-EMA thickness gauge has several advantages:

  • CONTACTLESS MEASUREMENT
  • MEASUREMENT THROUGH PAINTED, OXIDIZED OR OILY SURFACES
  • HIGH TEMPERATURE PROBES
  • AUTOMATIC OPERATION MODE AND VARIOUS TYPES OF SIGNAL DISPLAYING



The UT-3M-EMA implements a unique operating mode – the device automatically analyzes the measured signals, selects the required measurement method, adjusts the parameters of the receiving path and displays the measured thickness on the device’s screen. Even an unskilled user with this mode will be able to accurately and rapidly measure the thickness of various metal structures and products.



Standard Kit includes:

  • Electronic unit
  • EMAT probe
  • Cable (2 Lemo 00 – 2 Lemo 00)
  • Calibration block
  • USB cable
  • Charger
  • Calibration certificate
  • Operation manual
  • Case

Please contact us for more information and pricing options.

(UT-3M-EMA)

SKU UT-3M-EMA
