The iS series Standard Salt Spray test Chamber from Ascott Analytical is a basic Corrosion Chamber with limited capabilities for single climate test programs.  Total test run-time and a specific temperature can be programmed and the salt mist fall-out rate can also be adjusted.

For humidity control please refer to the iP series salt spray chambers.

One of the most common Neutral pH salt spray testing standards is ASTM B117 and is factory preset into the chamber memory.  Additional test standards can be added and edited in the program menu as needed by using the simple touch screen user interface.

These iS series corrosion chambers are available in a wide range of sizes from a bench top 120L capacity unit through to the floor standing models from 450L to 2,600L capacity. They require De-ionised water, standard single phase 240V power supply and clean, dry, oil free compressed ir.

A range of consumables and accessories are also available to customise the unit to your requirements such as additional racking, side entry port, interior illumination, exhaust scrubber, waste water trough and spare part kits just to name a few.

Please contact us on (03) 8787 3636 for further information and to discuss your requirements in detail to be able to customise a package for you.

FEATURES:

  • Basic Salt Mist testing
  • User adjustable temperature & time settings
  • Ergonomic and aesthetic
  • Interior viewing window



SPECIFICATIONS:

Standard Salt Spray Chamber S120iS S450iS S1000iS S1300iS S2000iS S2600iS
Chamber Capacity 120L 450L 1000L 1300L 2000L 2300L
Mounting Format Bench Top Floor Standing
Loading Threshold 280mm 800mm
Chamber External Dimensions 131 x 68 x 80cm 166 x 84 x 151cm 202 x 120 x 172 cm 202 x 115 x 190cm 288 x 120 x 172cm 288 x 115 x 190cm
Chamber Internal Dimensions 71 x 49 x 49cm 101 x 64 x 114cm 130 x 98 x 132cm 130 x 98 x 152cm 216 x 98 x 132cm 216 x 98 x 152cm
Air Clean, dry and oil fee 4 to 6 bar (58~87psi). 240 Lt per minute flow
Water Deionized and distilled at 0.5 to 5 bar (7.3~73psi)
Power 240V, 1 phase, 50Hz  415V, 3 phase, 50Hz









(SSiS)

• Continuous, single climate corrosion testing
• Neutral pH salt spray standard ASTM B117
• Capacity range 120L to 2600L
• User adjustable temperature and time settings

SKU SSiS
Brand Ascott Analytical
